Seat Leon >> Front reading lights

Fig. 78 Interior roof

Fig. 78 Interior roof lining: Front lights

Switching on the reading light Press the button B to switch on the reading light.
 Press the button B to switch on the reading light.

Switching off the reading lights Press the button B to switch off the reading light.
 Press the button B to switch off the reading light.
