Seat Leon >> Location overview - Sound system
SEAT Leon Service and Repair Manual / Communication / Communication / Sound system / Location overview - Sound system
Location overview - Sound system, 2-door vehicle
- - Screw
- 3 Nm
- - Centre loudspeaker - R208-
- Removal and installation
- - Multi-pin connector, 6-pin
- - Front interior light - W1-
- Assembly overview
- - Telephone microphone -
R38-
- Assembly overview
- Removal and installation
- - Rear left treble loudspeaker
- R14- / rear right treble loudspeaker
- R16-
- Removal and installation
- - Subwoofer - R211-
- Removal and installation
- - Screw
- 3 Nm
- - Screw
- 3 Nm
- - Rear left bass loudspeaker
- R15- / rear right bass loudspeaker
- R17-
- Removal and installation
- - Screw
- 2 Nm
- - Front left bass loudspeaker - R21- / front right bass loudspeaker -
R23-
- Removal and installation
- - Front left treble loudspeaker - R20- / front right treble loudspeaker
- R22-
- Removal and installation
Location overview - Sound system, 4-door vehicle
- - Screw
- 3 Nm
- - Centre loudspeaker - R208-
- Removal and installation
- - Multi-pin connector, 6-pin
- - Front interior light - W1-
- Assembly overview
- - Telephone microphone -
R38-
- Assembly overview
- Removal and installation
- - Rear left treble loudspeaker
- R14- / rear right treble loudspeaker
- R16-
- Removal and installation
- - Subwoofer - R211-
- Removal and installation
- - Screw
- 3 Nm
- - Screw
- 3 Nm
- - Rear left bass loudspeaker
- R15- / rear right bass loudspeaker
- R17-
- Removal and installation
- - Screw
- 2 Nm
- - Front left bass loudspeaker - R21- / front right bass loudspeaker -
R23-
- Removal and installation
- - Front left treble loudspeaker - R20- / front right treble loudspeaker
- R22-
- Removal and installation
Sound system
...
Removing and installing rear treble
loudspeakers R14 / R16
Removing and installing rear treble
loudspeakers R14 / R16, 2-door vehicle
Note
The removal and installation of the rear left treble loudspeaker -
R14- is described. The removal and installation o ...
